uvicorn

The lightning-fast ASGI server.


Introduction

Uvicorn is a lightning-fast ASGI server, built on uvloop and httptools.

Until recently Python has lacked a minimal low-level server/application interface for asyncio frameworks. The ASGI specification fills this gap, and means we're now able to start building a common set of tooling usable across all asyncio frameworks.

ASGI should help enable an ecosystem of Python web frameworks that are highly competitive against Node and Go in terms of achieving high throughput in IO-bound contexts. It also provides support for HTTP/2 and WebSockets, which cannot be handled by WSGI.

Uvicorn currently supports HTTP/1.1 and WebSockets. Support for HTTP/2 is planned.


Quickstart

Requirements: Python 3.5, 3.6, 3.7

Install using pip:

$ pip install uvicorn

Create an application, in app.py:

class App():
    def __init__(self, scope):
        self.scope = scope

    async def __call__(self, receive, send):
        await send({
            'type': 'http.response.start',
            'status': 200,
            'headers': [
                [b'content-type', b'text/plain'],
            ]
        })
        await send({
            'type': 'http.response.body',
            'body': b'Hello, world!',
        })

Run the server:

$ uvicorn app:App

Usage

The uvicorn command line tool is the easiest way to run your application...

Command line options

$ uvicorn --help
Usage: uvicorn [OPTIONS] APP

Options:
  --host TEXT                     Bind socket to this host.  [default:
                                  127.0.0.1]
  --port INTEGER                  Bind socket to this port.  [default: 8000]
  --uds TEXT                      Bind to a UNIX domain socket.
  --fd INTEGER                    Bind to socket from this file descriptor.
  --loop [auto|asyncio|uvloop]    Event loop implementation.  [default: auto]
  --http [auto|h11|httptools]     HTTP parser implementation.  [default: auto]
  --ws [none|auto|websockets|wsproto]
                                  WebSocket protocol implementation.
                                  [default: auto]
  --wsgi                          Use WSGI as the application interface,
                                  instead of ASGI.
  --debug                         Enable debug mode.
  --log-level [critical|error|warning|info|debug]
                                  Log level.  [default: info]
  --no-access-log                 Disable access log.
  --proxy-headers                 Use X-Forwarded-Proto, X-Forwarded-For,
                                  X-Forwarded-Port to populate remote address
                                  info.
  --root-path TEXT                Set the ASGI 'root_path' for applications
                                  submounted below a given URL path.
  --limit-concurrency INTEGER     Maximum number of concurrent connections or
                                  tasks to allow, before issuing HTTP 503
                                  responses.
  --limit-max-requests INTEGER    Maximum number of requests to service before
                                  terminating the process.
  --timeout-keep-alive INTEGER    Close Keep-Alive connections if no new data
                                  is received within this timeout.  [default:
                                  5]
  --help                          Show this message and exit.

For more information, see the settings documentation.

Running programmatically

To run uvicorn directly from your application...

import uvicorn

class App:
    ...

if __name__ == "__main__":
    uvicorn.run(App, "127.0.0.1", 5000, log_level="info")

Running with Gunicorn

Gunicorn is a mature, fully featured server and process manager.

Uvicorn includes a Gunicorn worker class allowing you to run ASGI applications, with all of Uvicorn's performance benefits, while also giving you Gunicorn's fully-featured process management.

This allows you to increase or decrease the number of worker processes on the fly, restart worker processes gracefully, or perform server upgrades without downtime.

For production deployments we recommend using gunicorn with the uvicorn worker class.

gunicorn app:App -w 4 -k uvicorn.workers.UvicornWorker

For a PyPy compatible configuration use uvicorn.workers.UvicornH11Worker.

For more information, see the deployment documentation.

The ASGI interface

Uvicorn uses the ASGI specification for interacting with an application.

The application should expose a callable which takes one argument, scope. This callable is used to create a new instance of the application for each incoming connection. It must return a coroutine which the server can then call into.

The application instance coroutine takes two arguments, (receive, send), which are the channels by which messages are sent between the web server and client application.

One style of implementation is to use a class with an __init__() method to handle application instantiation, and a __call__() coroutine to provide the application implementation.

class App():
    def __init__(self, scope):
        self.scope = scope

    async def __call__(self, receive, send):
        ...

The content of the scope argument, and the messages expected by receive and send depend on the protocol being used.

The format for HTTP messages is described in the ASGI HTTP Message format.

HTTP Scope

An incoming HTTP request might instantiate an application with the following scope:

{
    'type': 'http.request',
    'scheme': 'http',
    'root_path': '',
    'server': ('127.0.0.1', 8000),
    'http_version': '1.1',
    'method': 'GET',
    'path': '/',
    'headers': [
        [b'host', b'127.0.0.1:8000'],
        [b'user-agent', b'curl/7.51.0'],
        [b'accept', b'*/*']
    ]
}

HTTP Messages

The instance coroutine communicates back to the server by sending messages to the send coroutine.

await send({
    'type': 'http.request.start',
    'status': 200,
    'headers': [
        [b'content-type', b'text/plain'],
    ]
})
await send({
    'type': 'http.request.body',
    'body': b'Hello, world!',
})

Requests & responses

Here's an example that displays the method and path used in the incoming request:

class EchoMethodAndPath():
    def __init__(self, scope):
        self.scope = scope

    async def __call__(self, recieve, send):
        body = 'Received %s request to %s' % (self.scope['method'], self.scope['path'])
        await send({
            'type': 'http.response.start',
            'status': 200,
            'headers': [
                [b'content-type', b'text/plain'],
            ]
        })
        await send({
            'type': 'http.response.body',
            'body': body.encode('utf-8'),
        })

Reading the request body

You can stream the request body without blocking the asyncio task pool, by fetching messages from the receive coroutine.

class EchoBody():
    def __init__(self, scope):
        self.scope = scope

    async def read_body(self, receive):
        """
        Read and return the entire body from an incoming ASGI message.
        """
        body = b''
        more_body = True

        while more_body:
            message = await receive()
            body += message.get('body', b'')
            more_body = message.get('more_body', False)

        return body


    async def __call__(self, receive, send):
        body = await self.read_body(receive)
        await send({
            'type': 'http.response.start',
            'status': 200,
            'headers': [
                [b'content-type', b'text/plain'],
            ]
        })
        await send({
            'type': 'http.response.body',
            'body': body,
        })

Streaming responses

You can stream responses by sending multiple http.response.body messages to the send coroutine.

class StreamResponse():
    def __init__(self, scope):
        self.scope = scope

    async def __call__(self, receive, send):
        body = await self.read_body(receive)
        await send({
            'type': 'http.response.start',
            'status': 200,
            'headers': [
                [b'content-type', b'text/plain'],
            ]
        })
        for chunk in [b'Hello', b', ', b'world!']
            await send({
                'type': 'http.response.body',
                'body': chunk,
                'more_body': True
            })
        await send({
            'type': 'http.response.body',
            'body': b'',
        })

Alternative ASGI servers

Daphne

The first ASGI server implementation, originally developed to power Django Channels, is the Daphne webserver.

It is run widely in production, and supports HTTP/1.1, HTTP/2, and WebSockets.

Any of the example applications given here can equally well be run using daphne instead.

$ pip install daphne
$ daphne app:App

Hypercorn

Hypercorn was initially part of the Quart web framework, before being separated out into a standalone ASGI server.

Hypercorn supports HTTP/1.1, HTTP/2, and WebSockets.

$ pip install hypercorn
$ hypercorn app:App

ASGI frameworks

You can use Uvicorn, Daphne, or Hypercorn to run any ASGI framework.

For small services you can also write ASGI applications directly.

Django Channels

The ASGI specification was originally designed for use with Django Channels.

Channels is a little different to other ASGI frameworks in that it provides an asynchronous frontend onto a threaded-framework backend. It allows Django to support WebSockets, background tasks, and long-running connections, with application code still running in a standard threaded context.

API Star

The API Star web framework supports both WSGI and ASGI modes.

Quart

Quart is a Flask-like ASGI web framework.

Starlette

Starlette provides a lightweight collection of tools for building ASGI services.

It includes request and response classes, an ASGI test client, routing, and static files support.
